Ruijie Reyee
This advanced ceiling-mounted wireless access point delivers next-generation Wi-Fi 7 performance with BE3600 dual-band capability, ideal for villas, retail spaces, and hospitality environments. Featuring a sleek, compact design, it supports up to 100 clients, offers AI-driven wireless optimisation, and integrates seamlessly with Reyee Mesh for expansive coverage. Designed for both easy installation and powerful standalone operation, it ensures stable, high-speed connections with robust security and management features.
Delivering cutting-edge wireless technology in a stylish form factor, this solution ensures consistent, high-speed coverage for demanding commercial and residential environments.
Product Specifications | |
---|---|
Wi-Fi Standards | 802.11a/b/g/n/ac/ax/be |
Max Throughput | 3570 Mbps (5 GHz: 2882 Mbps, 2.4 GHz: 688 Mbps) |
Spatial Streams | 2x2 MIMO on both 2.4 GHz and 5 GHz |
Antenna Type | Omni-directional (5 GHz: 4.44 dBi, 2.4 GHz: 3.23 dBi) |
Channel Width | 5 GHz: Auto/20/40/80/160 MHz, 2.4 GHz: Auto/20/40 MHz |
Transmit Power | 5 GHz: ≤ 25.7 dBm, 2.4 GHz: ≤ 25 dBm (country-dependent) |
Service Ports | 1 x 10/100/1000/2.5GBASE-T |
Power Supply | 12 V DC, 1.5 A or 802.3af/802.3at PoE |
Power Consumption | ≤ 14 W |
Dimensions | Ø195 mm x 41 mm |
Weight | ≤ 0.6 kg |
Operating Temperature | 0°C to 40°C |
IP Rating | IP41 |
Management | Ruijie Cloud, Reyee App, Local Web Interface |
Security | WPA3, WPA2, WPA, OWE, 802.1X |
General Information | |
---|---|
Manufacturer: | Ruijie Reyee |
Manufacturer Part Number: | RG-RAP72 |
Barcode: | 90012596 |
Packaging Details | |
Weight: | 0.60 KGS |
Width: | 5.00 (cm) |
Height: | 5.00 (cm) |
Depth: | 20.00 (cm) |
