Ruijie Reyee RG-RAP6260(G) AX1800 WiFi 6 Outdoor WiFi Access Point (PSU sold separately)
Ruijie Reyee RG-RAP6260(G) AX1800 WiFi 6 Outdoor WiFi Access Point (PSU sold separately)
The Reyee RG-RAP6260(G) is a high-performance outdoor WiFi access point, suitable for commercial environments offering 574 Mb/s over 2.4 GHz and 1201 Mb/s over 5 GHz, providing up to 1.8 Gbps of WiFi throughput. As an 802.11ax WiFi-6 access point, multiple RAP6260G units can be used to cover large outdoor spaces, for connectivity around buildings, carparks, schools, or for public WiFi. The included bracket supports wall, horizontal, and vertical installations. Managed by the Ruijie Cloud Platform, the RAP6260G features auto-discovery and provisioning, self-organisation, and self-configuration. The unit should be connected to the network by wired backhaul (via SFP or Gigabit Ethernet RJ45).
FEATURES:
- Compatible with POE+ RG-E-130(GE)
- 802.11ax WiFi-6 supporting speeds up to 1775 Mbps
- Dual-band dual stream (2x2:2)
- Managed with Ruijie Cloud Controller for seamless onboarding and roaming between APs
- Up to 512 simultaneous users per access point (100 recommended)
- 802.3af/at PoE or 12 Vdc power supply
- 1x gigabit ethernet port, 1x gigabit SFP Port
Technical Specification | Specification Description |
---|---|
Model | RG-RAP6260(G) |
Radio | Dual-stream dual-band |
Protocol | Concurrent 802.11a/b/g/n/ac/ax |
Operating Bands | 802.11b/g/n/ac/ax: 2.4G ~ 2.4835GHz 802.11a/n/ac/ax: 5G: 5.150~5.350GHz, 5.725~5. (country specific) |
Antenna | Internal antennas (2.4GHz: 4dBi, 5GHz: 6dBi) |
Spatial Streams | 2.4 GHz 2x2 MU-MIMO 5 GHz 2x2 MU-MIMO |
Max Throughput | Up to 574Mbps at 2.4GHz Up to 1201Mbps at 5GHz Totally 1775Mbps per AP |
Modulation | DBPSK/DQPSK/CCK(DSSS)/BPSK/QPSK/16QAM/64QAM/256QAM/1024QAM |
Receive Sensitivity |
11b: -91dBm(1Mbps), -88dBm(5Mbps), -85dBm(11Mbps) 11a/g: -89dBm (6Mbps), -80dBm (24Mbps), -76dBm (36Mbps), -71dBm (54Mbps) 11n: -83dBm @ MCS0, -65dBm @ MCS7, -83dBm @ MCS8, -65dBm @ MCS15 11ac HT20: -83dBm (MCS0), -57dBm (MCS9) 11ac HT40: -79dBm (MCS0), -57dBm (MCS9) 11ac HT80: -76dBm (MCS0), -51dBm (MCS9) 11ax HE80: -82dBm (MCS0), -57dBm (MCS9), -52dBm (MCS11) |
Maximum Output Power of the Transmitter (Single Stream) |
2.4GHz (2.4~2.4835GHz): 26dBm 5GHz (5.150~5.250GHz, 5.725~5.850GHz): 25dBm (country-specific, comply with local laws) |
Adjustable Power | 1dBm |
Dimensions | 298mm × 298mm × 65mm (excluding mounting kits) |
Weight | ≤1.35kg (excluding mounting kits) |
Service Ports |
1 10/100/1000 Base-T Ethernet port supports PoE IN 1 100/1000 Base-X SFP Port |
Management Port | N/A |
LED Indicator | Single indicator (Blue light) |
Power Supply | 802.3at PoE (Warning: 802.3af or non-standard POE adapter may cause unknown issues. Please use Ruijie POE+ switch or 802.3at POE adapter as power supplier) |
Power Consumption | ≤17W |
Bluetooth | Support |
Environment |
Operating Temperature: -40°C ~ 65°C Storage Temperature: -40°C ~ 85°C Operating humidity: 0% ~ 100%, non-condensing Storage humidity: 0% ~ 100%, condensing/non-condensing |
Installation | Pole/Wall-Mountable |
Safety Standard | GB4943, IEC 60950-1 |
EMC Standard | GB9254, EN301 489, EN50155: EN50121 |
Vibration Standard | IEC61373 |
Radio Standard | EN300 328, EN301 893 |
MTBF | >400000H |
WLAN |
Maximum number of clients: 512 Recommended number of clients: 100 Up to 8 SSID Support SSID hiding Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID SSID-based and radio-based STA limit Support Layer 2 user isolation Support Reyee Mesh |
Roaming | Support layer 2 and layer 3 roaming |
Security |
Support PSK authentication Support static blacklist and whitelist Support WPA (TKIP), WPA2 (AES), WPA-PSK data encryption |
Routing | Support static IP address, DHCP, PPPoE Dial |
Management and Maintenance |
Support unified networking of all network equipment Support local or remote management with Ruijie Cloud APP Support local management with web Support remote management with Ruijie Noc Cloud platform |
Platform Management Features |
Automatic RF adjustment via the platform Unified configuration via the platform Unified monitoring via the platform |
General Information | |
---|---|
Manufacturer: | Ruijie Reyee |
Manufacturer Part Number: | RG-RAP6260(G) |
Barcode: | 6971693272187 |
Packaging Details | |
Weight: | 1.35 KGS |
Width: | 30.00 (cm) |
Height: | 7.00 (cm) |
Depth: | 30.00 (cm) |
