EZVIZ
This smart Wi-Fi chime ensures you never miss a visitor while improving the stability of your doorbell connection. Designed for seamless integration, it amplifies the Wi-Fi signal, extends coverage, and delivers instant audio notifications. With a selection of ringtones and adjustable volume, it provides a customisable and convenient experience for any home.
Enhance your home’s security and convenience with a reliable chime that ensures you stay connected and alerted at all times.
| Specifications | |
|---|---|
| Model | CS-CH1-R100-10AWFK |
| Audio | |
| Ringtone | Supports up to 20 options with adjustable volume |
| Audio Output | Built-in high-power speaker (Up to 72 dB in 1 meter) |
| Network | |
| Protocol | EZVIZ Cloud Proprietary Protocol |
| Interface Protocol | EZVIZ Cloud Proprietary Protocol |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20 MHz |
| Security | 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
| Transmission Rate | 11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps |
| Antennas | Dual external antennas |
| General | |
| Operation Conditions | -10°C to 45°C (14°F to 113°F), humidity 95% or less (non-condensing) |
| Dimensions | 101 × 64 × 32 mm (3.98 × 2.52 × 1.26 inch) |
| Package Dimensions | 113 × 85 × 95 mm (4.45 × 3.35 × 3.74 inch) |
| Power Consumption | Max. 5W |
| Power Supply | AC 100 ~ 240V |
| Net Weight | 87 g (3.07 oz) |
| Weight with Package | 178 g (6.28 oz) |
| Reset Button | Yes |
| General Information | |
|---|---|
| Manufacturer: | EZVIZ |
| Manufacturer Part Number: | CS-CH1-R100-10AWFK |
| Barcode: | 90012263 |
| Packaging Details | |
| Weight: | 0.50 KGS |
| Width: | 7.00 (cm) |
| Height: | 4.00 (cm) |
| Depth: | 10.00 (cm) |
